ELAC – Authorised Dealer Information

Audio Trust is an Authorised Dealer for ELAC.

Purchase with confidence from Audio Trust to receive genuine ELAC products sourced through authorised channels, ensuring authenticity, reliable performance, and dependable after-sales support. Avoid unauthorised sellers to ensure you receive original products with proper manufacturer support.

ELAC Concentro S 503 Bookshelf Speaker

The ELAC Concentro S 503 is a premium 3-way bass reflex bookshelf speaker that brings the advanced design and technology of the Concentro series into a more compact package. It combines an AS-XR woofer and midrange driver with ELAC’s JET 5C tweeter, while its exchangeable Directivity Control Rings allow the sound dispersion to be adjusted according to the listening environment.

Key Features

• Premium 3-way bass reflex bookshelf speaker
• 180mm AS-XR crystal membrane woofer
• 130mm AS-XR aluminium midrange driver
• ELAC JET 5C tweeter
• Exchangeable Directivity Control Ring (DCR) technology
• Trapezoidal cabinet with convex-shaped baffle
• Adjustable midrange directivity for different room acoustics
• Bi-wiring capability
• Optional LS 100 speaker stand
• Available in High-Gloss Black, White and Walnut finishes

Specifications

• Speaker Type: 3-way bass reflex
• Woofer: 1 × 180mm AS-XR cone
• Midrange: 1 × 130mm AS-XR aluminium cone
• Tweeter: JET 5C
• Crossover Frequencies: 400Hz / 2.6kHz
• Sensitivity: 87dB / 2.83V/m
• Nominal Impedance: 4 Ohms
• Recommended Amplifier Power: 60–500W per channel
• Peak Power Handling: 400W
• Dimensions (H × W × D): 400 × 225 × 372mm
• Weight: 13.4kg each
• Finishes: High-Gloss Black, White Lacquer, Walnut Veneer
• Accessories: Bi-wiring jumper set and 3 DCR rings
