Anthem MCA 225 Gen 2

The Anthem MCA 225 Gen 2 is a high-performance 2-channel power amplifier designed for demanding stereo and home theatre systems. Delivering 225W per channel into 8Ω, with robust power output into lower impedances, a low-noise toroidal transformer, high-current bipolar output devices and Advanced Load Monitoring, it is engineered for clean, controlled and reliable performance.

Key Features

• 2-channel power amplifier
• 225W per channel into 8Ω
• 400W per channel into 4Ω
• 600W per channel into 2Ω
• Custom low-noise, high-power toroidal transformer
• High-current bipolar output transistors
• 8 bipolar output devices per channel
• Advanced Load Monitoring (ALM™)
• Oversized aluminium heatsinks
• Redesigned circuit path with reduced internal cabling
• RCA and balanced XLR inputs
• Automatic, trigger and manual power control
• Low standby power consumption
• Audiophile-grade binding posts
• 120dB signal-to-noise ratio
• Made in Canada

Specifications

• Channels: 2
• Power Output: 225W/ch @ 8Ω
• Power Output: 400W/ch @ 4Ω
• Power Output: 600W/ch @ 2Ω
• Frequency Response: 20Hz–20kHz ±0.1dB @ 8Ω and 4Ω
• Frequency Response: 20Hz–20kHz ±0.2dB @ 2Ω
• Signal-to-Noise Ratio: 120dB
• THD + Noise: 0.0010% @ 1kHz, 0.002% @ 20kHz
• Input Impedance: 10kΩ RCA / 15kΩ XLR
• Input Sensitivity: 1.5Vrms
• Voltage Gain: 29dB
• Slew Rate: 30V/μs
• Damping Factor: 300
• Power Bandwidth: 90kHz
• Standby Power: 1W
• Dimensions: 17.25″ W × 6.625″ H × 18.125″ D
• Rack Height: 4U
• Weight: 40 lbs / 18kg
• Finish: Black
• Country of Manufacture: Canada
